9005 HB3 LED Bulb Install Guide

What Does the 9005 HB3 Halogen Bulb Look Like?

The 9005 HB3 halogen bulb is a high-beam bulb commonly used in many vehicles to provide powerful, long-range illumination.

This bulb has a compact design with a clear glass exterior, designed to emit a bright, focused light. It features a plastic base with a two-pronged plug, allowing for an easy connection to your vehicle's electrical system. The plug design ensures that the bulb fits securely into the headlight housing and stays in place, even during rough driving conditions.

Common Vehicle Models That Use 9005 HB3 Bulbs

The 9005 HB3 halogen bulbs are widely used in many car models for their high-beam or fog light applications. Here are some common vehicle models that utilize this type of bulb:

-1992-2020 Ford (model: Explorer, Expedition, Escape, Edge, F-150, Transit-150/250/350 etc.)
-1990-2020 Chevrolet (model: SSR, S10, C1500/2500/3500, Silverado, Express, Tahoe, Suburban, Sonic etc.)
-1988-2020 Honda (model: Accord, Civic, Crosstour, Pilot, etc)
-1990-2020 Nissan (model: 240SX, 300ZX, Altima, Titan, Murano, Quest, Juke, Leaf etc.)
-1999-2020 Jeep (model: Grand Cherokee, Cherokee, Compass, Commander etc.)
-1988-2014 GMC (model: C1500/C2500/C3500, Yukon XL 1500, Sierra 1500/2500/3500, Yukon, Savana 1500, Envoy, Canyon, Terrain etc.)
-1998-2020 Dodge (model: Intrepid, Viper, Colt, Durango, Ram 1500/2500/3500, Journey, Avenger, Charger, etc.)
-1987-2004 BMW (model: 735, M6, L6, 325, 635CSi, 540i, 850i, Z8, M3, Z3, X5 etc.)
-2011-2012 Ram (model: 1500/2500/3500, ProMaster City, 1500 Classic etc.)
-1992-2019 Mazda (model: 929, 626, Millenia, Miata, CX-7, CX-9, CX-3 etc.)
-1998-2020 Chrysler (model: Concorde, 300M, Pacifica, Sebring, PT Cruiser etc.)
-And More

These vehicles rely on the 9005 HB3 bulb due to its reliable performance and excellent beam pattern, making it a popular choice for high-beam headlights.

How do I find the right LED bulb for my vehicle?

There are two methods to help you find the right light bulb:
1) Click here to go to our vehicle bulb finder, enter the year, model, etc. of your vehicle to get the right bulbs for your vehicle.
2) Please contact us at service@novsight.com and tell us the year and model of your vehicle, as well as the type of headlight you are interested in, our professional customer service team will get back to you as soon as possible.

9005 HB3 Bulb Installation Tutorial

Upgrading to 9005 HB3 LED bulbs is a great way to enhance your vehicle's lighting system, providing brighter light output, improved energy efficiency, and a longer lifespan compared to traditional halogen bulbs. Follow this 9005 HB3 LED bulbs installation guide to seamlessly replace your current halogen bulbs with more advanced LED technology.

Tools Needed:

Gloves or a clean cloth (to handle the bulbs safely)
Flathead screwdriver or trim removal tool (for removing any covers or housing, if necessary)
New 9005 HB3 LED bulbs

Step-by-Step Installation

Step 1: Prepare Your Vehicle:

Park your vehicle on a flat surface and turn off the engine. Allow the headlights to cool completely before handling the bulbs to avoid burns or damage.
Open the hood to access the back of the headlight assembly.

Step 2: Access the Headlight Housing:

Locate the headlight housing that contains the 9005 HB3 halogen bulb. Depending on your vehicle model, you may need to remove a dust cover or other components with a flathead screwdriver or trim removal tool to access the bulb.

Step 3: Remove the Old 9005 HB3 Halogen Bulb:

Twist the bulb counterclockwise to unlock it from the socket.
Gently pull the bulb out of the housing, then disconnect the wiring harness by pressing the release tab and pulling the connector away from the bulb.

Step 4: Install the New 9005 HB3 LED Bulbs:

Take the new 9005 HB3 LED bulbs and connect them to the wiring harness. Ensure the connector is securely attached to the bulb.
Insert the LED bulb into the headlight housing and twist it clockwise to lock it in place. Make sure the bulb is fully seated and secure in the socket.

Step 5: Test the New Bulbs:

Turn on your vehicle’s headlights and test the new 9005 HB3 LED bulbs. Check both high beams to ensure proper function and brightness.
If the bulbs don’t turn on, try flipping the connector 180 degrees and reconnecting it, as some LED bulbs are polarity sensitive.

Step 6: Reassemble the Headlight Components:

Once the new 9005 HB3 LED install is successful, replace any covers or components you removed during the installation process.Double-check that everything is secure and properly aligned before closing the hood.

Points to Pay Attention To

Gloves or Cloth: Always wear gloves or use a clean cloth when handling bulbs to prevent oils from your skin from contaminating the glass, which can cause damage.
Polarity Sensitivity: LED bulbs are often polarity sensitive, meaning they need to be installed in the correct orientation. If the bulbs don’t light up, reverse the polarity by flipping the plug and reconnecting.
Secure Fitting: Ensure the new LED bulbs are fully locked into place and don’t wobble, as improper installation can lead to poor beam performance or damage to the bulbs.

If you want to learn more about: 9006 HB4 halogen bulb same as the 9005 HB3?

Conclusion

By following this 9005 HB3 LED bulbs installation guide, you’ve successfully upgraded your vehicle’s headlights from traditional halogen bulbs to modern, energy-efficient LEDs. This OME halogen bulb update not only provides brighter light output but also ensures a longer lifespan and improved durability for your vehicle’s lighting system. For additional support, check out the following video that demonstrates the installation process step-by-step.

Completing the 9005 HB3 OME halogen bulb update improves both the safety and appearance of your vehicle’s lighting system, ensuring better visibility on the road and a sleek, modern look.
